A short review of the latest V-NAND SSD from Samsung – 970 EVO NVMe M.2

 It has been a week since Samsung released its latest NVMe SSD, 970 EVO and 970 PRO. Since the announcement, I was eagerly waiting to get my hands on the 970 EVO. The windows installation on my desktop was running from an old 80 GB HDD. It was OK since I use that installation mainly for mining and for trying out games. Then I stumbled across Universe Sandbox ², an awesome universe simulator. Which made me think about  switching the installation to an SSD. So I thought, why not the latest NVMe drive, and there were two M.2 slots free on my Z370 motherboard.
970_EVO installation
970 EVO in M.2 PCIex4 slot

The first impression was, damn it is too small (M.2-2280 ), smaller than a RAM stick and the performance is mind blowing. 3.5GB/s read and 1.5 GB/s write. Yes, it is big B for byte. You can copy a GB file in less than a second. Samsung upgrades the warranty to 5 years starting with 970 SSD. I have my main Ubuntu installation on a 2.5 inch SATA III 850 EVO, that drive is nowhere close to the gigabyte territory of PCIe. May be I will switch the drives later.
970 evo review
970 EVO uses the latest vertical NAND structure to store bits. Being working on similar technologies, I was quiet intrigued by the design. The bit cell itself looks like a cylinder with rings(the gate wraps around). The bit-line coming through the core vertically and the word-lines by the side in multiple layers (24 layers for first gen, 32 for second gen, 48 for third gen and 64 layers for 970 EVO, fourth generation).  Here is the link to Samsung V-NAND white paper.

v-nand 970 EVO
3D Layout of V-NAND. Image Credit –Chipworks







It took 3 days for UPS to deliver to Bangalore, India through regular shipping which I ended up paying 169$ for a 109$ drive including all duties and taxes. I was hopping to spent at least a day to migrate all the installation to the new drive. Samsung surprised me again, In the support page of 970 EVO, you can find ‘Samsung Data Migration’ software which clones the installation which is currently active to the new drive. Just pop-in the drive, install latest NVMe drivers from Samsung support page, open Samsung Data Migration and few clicks to clone the drive. It took just 10 minutes to clone full HDD to NVMe drive and I booted through the new drive directly after clone, that easy. The boot time was just around 10 seconds.


Getting started with OpenAI Gym – Part 1, Installation and configuration

OpenAI Gym toolkit provides easy visualisation tools to experiment with reinforcement learning algorithms. Here I will explain the process of setting it up and the issues I have faced.

Installation instructions are given in the github page. While I was trying in the default terminal I was getting issues with python dependencies and different versions of packages installed in the system. So I tried with a virtual environment to set up gym.  First, I have added the Anacaonda path to create a virtual environment.

export PATH="/<installation path>/anaconda3/bin:$PATH"

create virtual environment.

conda create -n py34 python=3.4
source activate py34
git clone https://github.com/openai/gym.git
cd gym
pip install -e .

This will install gym, if you are getting error saying swig not found. Install the dependencies,

sudo apt-get install python python-setuptools python-dev python-augeas gcc swig dialog

Run the sample program.

>import gym
>env = gym.make('LunarLander-v2')

If everything is installed correctly, It will render this frame,

OpenAi gym lunar lander getting started

If there is an error regarding Box2D library, install it manually.

pip3 uninstall Box2D box2d-py
git clone https://github.com/pybox2d/pybox2d
cd pybox2d/
python setup.py clean
python setup.py build
python setup.py install

OpenAI gym needs OpenGL drivers to be configured in the machine. I have got issues with nvidia driver (nvidia-smi). So I tried switching to an older driver. This can be done through ‘Software Updater->Additional Drivers’.

OpenGl driver OpenAI Gym Nvidia

OpenGl driver can be tested by running glxgears  in terminal. If installed correctly, it shows up this image with animation.

OpenAI OPENGL configuration nvidia driver issue

For using MuJoCo physics engine, mujoco-py needs to be installed separately. The instructions are given here. Before running mujoco examples, add these paths to your .bashrc

export LD_LIBRARY_PATH=$LD_LIBRARY_PATH:/home/kiran/.mujoco/mjpro150/bin
export LD_LIBRARY_PATH=$LD_LIBRARY_PATH:/usr/lib/nvidia-390
#If there is OpenGL error
export LD_PRELOAD=/usr/lib/x86_64-linux-gnu/libGLEW.so:/usr/lib/nvidia-390/libGL.so



Custom image detector using Tensorflow object detection API

The aim of this tutorial to use tensorflow object detection API to detect custom objects. Here in this tutorial, we will try to train the network to recognize battery charging image (Why battery charging ? later, this trained net can be used in a robot to detect the charging point from a picture). This is basically an excerpt of sentdex tensorflow tutorial series. I have listed out the steps which I have done to train custom image for quick access.

Download files here

battery charging image detection
Image to detect

To train the model, first we need to collect training data. This can be done by collecting images from google images. I used a chrome extension ‘Fatkun Batch Download Image’ for saving bulk images. Once the images are downloaded, download and install labelImg to annotate the training data.

git clone https://github.com/tzutalin/labelImg.git
sudo apt-get install pyqt5-dev-tools
sudo pip3 install lxml
make qt5py3
python3 labelImg.py

Browse to the image folder that contains downloaded  images. The idea is to create xml label for all the images. Select the image one by one, Click create rectangle box, give the label as ‘charging sign’ and save as xml file(default). labelImg-tensorflow

Create train and test directory. Copy 10% of images with respective xml label file to test directory and remaining 90% to train directory.

Run modified xml_to_csv.py from datitran’s github  to create ‘train/test_labels.csv’. The directory structure is as follows.

Next step is to generate tfrecord for test and train data from generated csv data. Use modified generate_tfrecord.py for this step and generate tfrecord for test and train data.

python3 generate_tfrecord.py --csv_input=data/train_labels.csv  --output_path=data/train.record

python3 generate_tfrecord.py --csv_input=data/test_labels.csv  --output_path=data/test.record

If you are getting error saying object_detection folder does not exist, export the below path. This tutorial needs tensor flow Object detection preinstalled.   Please follow this link for more information

# From tensorflow/models/research/
export PYTHONPATH=$PYTHONPATH:`pwd`:`pwd`/slim

Copy data, training, images and  ssd_mobilenet_v1_coco_11_06_2017 directories to tensorflow object_detection folder and start training.

wget http://download.tensorflow.org/models/object_detection/ssd_mobilenet_v1_coco_11_06_2017.tar.gz

python train.py --logtostderr --train_dir=training/ --pipeline_config_path=training/ssd_mobilenet_v1_pets.config

ssd_mobilenet_v1_pets.config will have paths to both tf records, graph and pbtxt file which contain the classes to detect. The checkpoint files will be created inside training directory.

Next we need to create a frozen inference graph from the latest checkpoint file created. Once done, use the inference program to detect the charging sign.

python export_inference_graph.py --input_type image_tensor
--pipeline_config_path training/ssd_mobilenet_v1_pets.config
--trained_checkpoint_prefix training/model.ckpt-9871
--output_directory charging_spot_det__inference_graph

python custom_inference.py

Since my training data set was small( less than 100) and there was only one class, the inference is buggy. It identifies almost everything as charging sign. but this can be extended with multiple classes and more training data to get accurate results.

A tiny Arduino project: Generic IR receiver using ATTiny85 and TL1838

This project uses a small arduino compatible microcontroller board called Digispark which is based on attiny85 chip. It has a PCB usb header which can directly communicate with PC through a USB bootloader. The board is relatively inexpensive compared to regular arduino board. As it comes with a usb connector, no other programmers are needed. It is best suited for projects which require less memory and few i/o pins.


Board setup

  • Go to, File->preferences->in ‘Additional Boards Manager URLs’ enter


  • Go to,  Tools->Board->Boards Manager->Contributed-> Install ‘Digistump AVR Board’


  • Install the drivers from here
  • Tools->Board->Select ‘Digispark (Default – 16.5mhz)’



  • Arduino code is here, the irPin is ‘p2’ of board which is connect to IR module TL1838, 300ms debounce time is added to avoid false triggering. There is an inbuilt LED which is connected to ‘p1’ that is turned ON and OFF with the IR pulse.
int irPin=2;
int onoff = 0;

void setup()
void loop()
    delay(300); // the debounce time 300ms;
    if(onoff == 0)
      onoff =1;
      onoff =0;
  • The code is looking for a low transition on the IR receiver to toggle pin 1, any IR remote can be used since this is a generic receiver which does not actually decode the IR signals.


  •  Programming is different from normal arduino boards since USB bootloader is active for first 10s from power on. After 10 seconds the board will switch from bootloader to sketch execution state. The board needs to be plugged-in where the arduino IDE shows notification for programming.

arduino digispark programming


  • Pin out of TL1838 is shown below,


  • The connection for IR module is shown below, IR input is connected to p2 of the board.

  • Any IR remote can be used to give the signal. Here is the board connected to a usb powerbank and controlled by TV remote


Setup for crypto mining on GIGABYTE Z370 HD3P motherboard: BIOS settings

When machine learning turns to mining,

Recently, I turned my desktop hardware which I assembled to learn AI into a mining rig. Most of the time, the desktop is sitting idle since my full time job is not on machine learning. So, it makes sense to mine on the hardware when I don’t use. I bought a couple of GPUs: 1050 Ti’s since, it is the only one available in market for a decent price, bought some pcie 1x to 16x risers and hooked up all those to make a mining rig. Here are the motherboard settings which worked for me to get it up and running with nicehash/ethminer. The motherboard is GIGABYTE Z370 HD3P with 6 PCIE slots.

  • Enter BIOS by pressing F12 while boot, click ‘Enter Setup’bootmenu_z370_mining
  • On the first tab ‘Motherboard Intelligent Tweaker’ click on ‘Miscellaneous Settings’pcie_gen2_for_mining_z370_hd3p
  • Choose Max link Speed to Gen2: default is Gen3, GPU don’t need Gen3 speed for mining. pcie_to_gen2_z370hd3p_mining
  • On BIOS tab, CSM support to Enabled and Fast boot to Disabledbios_settings_z370_hd3p_mining
  • On Peripherals tab, Graphics to internal Intel HD (IGFX) and 4G decoding to Enabled. Connect Display to Motherboard HDMI slot. peripheral_settings_z370_hd3p_mining
  • On Chipset tab, Enable Internal GFX. Save and Reboot.chipset_settings_z370_hd3p_mining

Install the drivers for GPU on device manager (right click on unknown device and click ‘Update driver’), If windows does not install it by default. Install nicehash miner and you are ready for mining.

Removing noise from video file in Linux using Audacity and kdenlive

Note: This is in Ubuntu 16.04

Removing the static noise picked up by the microphone is essential before uploading youtube videos since youtube does not allow editing audio track after the upload. It stopped allowing annotations in videos too, so the only way to remove noise after uploading is to take down the video and upload a new video. Unfortunately I had to do the same, just explaining here how to do the editing using freeware in ubuntu.

To remove noise, we need two software,

1)Audacity – Install it from Ubuntu Software
use audacity to remove noise


sudo add-apt-repository ppa:sunab/kdenlive-release
sudo apt-get update
sudo apt-get install kdenlive

Initial step is two create a audio file which is free from noise from the video file using Audacity.
Open Audacity-> File->Open (open video file)

audacity noise removal

Select noise as shown in fig above; Effect->Noise Reduction: Step 1 – Get Noise Profile (this will tell audacity which is the noise signature)
Noise Reduction_audacity

Deselect the noise (click anywhere outside the selection); Effect->Noise Reduction: Step 2 – OK (keep default settings or change Noise reduction settings in db for more attenuation)

noise attenuated file audacity

File->Export Audio->Save as noise_free.mp3


We use kdelive to merge the noise free audio track to the video track.

Open kdelive,
menu->Projects->Add clip->Add the original video with noisy audio
menu->Projects->Add clip->Add the noise free audio file (noise_free.mp3)
kdelive creating new audio track for youtube video in ubuntu

Drag the video to Video 1, drag noise_free.mp3 to Audio 1, mute Video 1 audio track. Go to project Monitor as press play button to check the new audio.

kdelive create videos for youtube with changing audio track

To save the new video Click on Render-> Render into a file (keep default settings or change settings whichever needed for file format)

See the comparisons below.

with noise
noise removed

Getting Tensorflow 1.4 working with NVIDIA DIGITS in Ubuntu 16.04

The steps to follow are here.

In this post, I am not explaining all the bits and pieces on how to install, I am trying to avoid the confusion regarding what to follow.

Here is the main dependency, If you need to train tensorflow model with NVIDIA DIGITS, you need to get DIGITS 6. If you have DIGITS 5 installed, It won’t detect tensorflow. At the time of writing, unlike installing DIGITS 5, there are no binaries provided by NVIDIA to install DIGITS 6. You need to either install using docker or compile and install from source. I tried installing from docker, later I figured out that unless you are already familiar with docker, you are going to spend hell a lot of time trying to understand docker itself and its usage. Then there is nvidia-docker, which is the one actually needed for NVIDIA DIGITS 6. I tried for some time and realised that it is not required for me since I own the machine and I am the only person using it. I really am not ready to spend time on going through docker pain at this point of time.

Even though I am not a fan of compiling and installing, looks like that’s the only way. It is going to take some time and, you may need to fix some build failures, dependencies, stack-overflowing, googling etc. I followed the installation instructions from DIGITS github page.

Long story short,  you need to,

  1. Remove DIGITS 5 ( check here how to list and remove packages)
  2. compile and install Caffe (can not skip this, it is a dependency for DIGITS 6)
  3. compile and install Torch (not a requirement but let’s keep it)
  4. compile and install tensorflow_gpu (I had this already, so I skipped)
  5. compile and install DIGITS 6

Make sure you add this variables to ~/.bashrc

export DIGITS_ROOT=~/digits
export CAFFE_ROOT=~/caffe
export TORCH_ROOT=~/torch

The digits server can be invoked by ‘digits-devserver &‘. By default the service will be active at http://localhost:5000/
If everything goes fine, when you create a new model in DIGITS you can see the frameworks.tensorflow on NVIDIA digits 6


Speech detection with Tensorflow 1.4 on Raspberry Pi 3 – Part 2: Live audio inferencing using PyAudio

Here is link to Part 1

Now we know, how to loop around the inferencing function, capture a voice for a fixed time and process it. What we need now is a program to listen to the input stream and measure the audio level. This will help us to take a decision if we need to capture the audio data or not.

File1: audio_intensity.py
The following code, reads a CHUNK of data from the stream and measure average intensity, prints it out so that we will know how much ambient noise is there in the background. First we need to figure out the average intensity level (INTENSITY) so that we will get a threshold number to check for.

import pyaudio
import wave
import math
import audioop
import time
p = pyaudio.PyAudio()
FORMAT = pyaudio.paInt16
RATE = 16000
CHUNK = 512
def audio_int(num_samples=50):
    print ('Getting intensity values from mic.')
    p = pyaudio.PyAudio()

    stream = p.open(format=FORMAT,
    #----------------------checks average noise level-------------------------
    cur_data = stream.read(CHUNK)
    values = [math.sqrt(abs(audioop.avg(cur_data, 4)))
                for x in range(num_samples)]
    values = sorted(values, reverse=True)
    r = sum(values[:int(num_samples * 0.2)]) / int(num_samples * 0.2)
    #---------------------prints out avg noise level--------------------------
    print (' Average audio intensity is r', r)

    return r

if(__name__ == '__main__'):
    while (True):
    audio_int()  # To measure your mic levels

File 2: audio_intensity_trigger.py
In this program, I have added an infinite loop and a check for INTENSITY level before printing the average audio level. If the room is silent or just background noise nothing is triggered. I have kept is as ‘11000’. Make sure that you change it according to output of audio_intensity.py. If its output is, say 8000, keep the intensity as 9000 or 10000.

while True:
  cur_data = stream.read(CHUNK)
  values = [math.sqrt(abs(audioop.avg(cur_data, 4)))
            for x in range(num_samples)]
  values = sorted(values, reverse=True)
  r = sum(values[:int(num_samples * 0.2)]) / int(num_samples * 0.2)
  #print " Finished "
  if (r > INTENSITY):
    print (' Average audio intensity is r', r)


File 3: audio_trigger_save_wav.py
his one will wait for the threshold and once triggered, it will save 1 second of audio to a file in wave format together with 5 frames of  previous voice chunks. This is important, otherwise our recording will not contain the starting of words or the words will be biased towards first half of 1 second and remaining half will be empty. The spectrogram when generated by tensorflow will looked chopped off.

    while True:
      #reading current data
      cur_data = stream.read(CHUNK)
      values = [math.sqrt(abs(audioop.avg(cur_data, 4)))
                for x in range(num_samples)]
      values = sorted(values, reverse=True)
      r = sum(values[:int(num_samples * 0.2)]) / int(num_samples * 0.2)
      if (r > INTENSITY):
        #-------------------------------------------------if triggered; file.wav = 5 previous frames + capture 1 sec of voice-------------------------------
        print (' Average audio intensity is r', r)
        frames = []
        #---------------getting 1 second of voice data-----------------
        for i in range(0, int(RATE / CHUNK * RECORD_SECONDS)):
          data = stream.read(CHUNK)
        print ('finished recording')
        #-------------     ---saving wave file-------------------------
        waveFile = wave.open(WAVE_OUTPUT_FILENAME, 'wb')
      #------------------------------------------------------if not triggered; saving previous values to a FIFO of 5 levels----------------------------------

File 4: wav_trigger_inference.py
his is the modified tensorflow inference file (label_wav.py).  I have fused the program audio_trigger_save_wav.py to label_wav.py. The usage is,

cd /tensorflow/examples/speech_commands
touch file.wav ; to create a dummy file for the first pass
python3 wav_trigger_inference.py --graph=./my_frozen_graph.pb --labels=./conv_labels.txt --wav=file.wav

The while loop is around run_graph(). If the audio is detected and is above threshold; wave file is captured and given for inferencing. Once the results are printed out, it continue listening for the next audio.

      with open(wav, 'rb') as wav_file:
        wav_data = wav_file.read()
      run_graph(wav_data, labels_list, input_name, output_name, how_many_labels)
      default=1,# -------------------this will make use that, it prints out only one result with max probability------------------------
      help='Number of results to show.')

Here is the result. There are some errors while processing since the graph is not accurate. I could train it only till 88% accuracy. More data argumentation is needed for improving the accuracy and I may need to fiddle around with all the switches that is provided by tensorflow for training. But this is good enough to create a speech controlled device using raspberry pi.

Speech detection with Tensorflow 1.4 on Raspberry Pi 3 – Part 1: Getting audio file using PyAudio

In previous posts 1 and about speech detection using tensorflow, it is shown how to inference a 1 sec audio sample using the graph that is trained in tensorflow by running label_wav.py. This series of posts will look into inferencing a continuous stream of audio. there is an excellent post  by Allan in medium.com which shows how to do the same but, I was not happy with the results and the code was quiet a lot to understand. It uses tensorflow audio functions to process the audio. I will be using pyAudio to process audio since it is easy to understand and later, I may move into tensorflow audio processing. The code posted is running on raspberry pi 3 but it should be able to run on any linux system without any modification.

To get the audio, you need to purchase a usb sound card as shown in the figure below, this is available in ebay/aliexpress or amazon. Connect a 2.5mm mic to it or like I did, scavenge a mic from old electronics and a 2.5mm audio jack and connect it together.

usb audio card on paspberry pi for tensorflow
USB microphone, pi noir camera and earphones for audio on raspberry pi 3

The following python code will record a 1 sec audio and save it as a .wav file. For tensorflow speech recognition we use a sampling rate of 16K (RATE), single channel (CHANNELS) and 1 sec duration (RECORD_SECONDS).

import pyaudio
import wave
FORMAT = pyaudio.paInt16
RATE = 16000
CHUNK = 512
audio = pyaudio.PyAudio()
# start Recording
stream = audio.open(format=FORMAT, channels=CHANNELS,
                rate=RATE, input=True,
print "recording..."
frames = []
for i in range(0, int(RATE / CHUNK * RECORD_SECONDS)):
    data = stream.read(CHUNK)
print "finished recording"
# stop Recording
waveFile = wave.open(WAVE_OUTPUT_FILENAME, 'wb')

When you run pyaudio.PyAudio() ALSA may print out errors like the one shown below.

ALSA error raspberry pi 3 tensorflow

The errors can be removed by commenting out the corresponding devices in /usr/share/alsa/alsa.conf.

alsa conf error raspberry pi 3

Next step is to integrate this to label_wav.py in tensorflow branch: tensorflow/examples/speech_commands/label_wav.py. In the updated file; mod_label_wav.py, I have added a for loop around run_graph() to record a 1 sec wav audio. A new audio sample will be recorded every time when the loop runs and the audio is rewritten with the same file name.

audio inferencing tensorflow raspberry pi

Here is the output. The input file is given as file.wav from the same directory …../speech_commands, the file will be overwritten each time when recording finishes. To start with, create a dummy file file.wav to run the script.

touch file.wav
wget https://github.com/kiranjose/python-tensorflow-speech-recognition/blob/master/mod_label_wav.py
python3 mod_label_wav.py --graph=./my_frozen_graph.pb --labels=./conv_labels.txt --wav=./file.wav

audio inferencing raspberry pi tensorflow

1. pyAudio_wav.py

2. mod_label_wav.py

This is by no means a great method to do speech inferencing. We need to wait for the script to record and again for the next command. But, this is the start. In the next post I will explain how to detect an audio threshold to activate the recording/inferencing. For this I have forked a google assistant speech invoking script written by jeysonmc, this will be the starting point.


Getting Tensorflow 1.4 on RaspberryPi 3

There are two methods to install tensorflow on raspberry pi, installing form binary which is provided by ci.tensorflow.org (you can get all nighly builds for all platform) or building from source which is hard and takes lots of time and setup. Build usually fails multiple times unless you know exactly what you do.

I will explain, how I installed tensorflow 1.4 on raspberry pi3 from pre-compiled binary.

Install pip,

# For Python 2.7
sudo apt-get install python-pip python-dev

# For Python 3.4
sudo apt-get install python3-pip python3-dev

Tensorflow nightly build for pi3 in python3 is avalilable here

Choose the date of the build, copy the link for .whl file.tensorflow nightly for raspberry pi 3

Install tensorflow, for python 3.4 use pip3 and pip for python 2.7.

sudo pip3 install http://ci.tensorflow.org/view/Nightly/job/nightly-pi-python3/39/artifact/output-artifacts/tensorflow-1.4.0-cp34-none-any.whl

or download it if you need a backup and install the file

wget http://ci.tensorflow.org/view/Nightly/job/nightly-pi-python3/39/artifact/output-artifacts/tensorflow-1.4.0-cp34-none-any.whl

sudo pip3 install ./tensorflow-1.4.0-cp34-none-any.whl

Test the installation,

$ python3
>>> import tensorflow as tf

If it is installed correctly, no errors will be shown. If there are errors while running, try uninstalling and install another nighty build binary. The tensorflow speech detection can be now run on raspberry pi after copying the files to the pi. Use scp for copying over ssh.

scp pi@192.168.1.xxx:my_frozen_graph.py /tmp/my_frozen_graph.py
scp pi@192.168.1.xxx:conv_labels.txt /tmp/speech_commands_train/conv_labels.txt
scp pi@192.168.1.xxx:a5d485dc_nohash_0.wav /tmp/speech_dataset/left/a5d485dc_nohash_0.wav

Make sure to clone the tensorflow tree from github to raspberry pi before running the label_wav.py

git clone https://github.com/tensorflow/tensorflow.git
cd tensorflow/examples/speech_commands

python tensorflow/examples/speech_commands/label_wav.py \
--graph=./my_frozen_graph.pb \
--labels=./conv_labels.txt \

running tensorflow speech detection on raspberry pi 3
